Aurora Sistema 200 AC/DC PULS TIG welder: max current 200 A

Name: Aurora Sistema 200 AC/DC PULS TIG welder: max current 200 A
Brand: Aurora
SKU: AP79236633
Price: 311114 AMD
Availability: InStock

Filter

Power (Watts)

MMA power consumption, kVA

Aurora Система 200 AC/DC ПУЛЬС TIG welder

New

In stock

Model: Система 200 AC/DC ПУЛЬС

Vendor code: AP79236633

Brand: Aurora

311,114֏

Price in reward points: 311114

Found it cheaper?

3111 points to the account

Payment

Delivery

Delivery within 2 hours.

Yerevan

3,000֏

Delivery within 24 hours.

Yerevan

Free

Delivery within 3 hours.

Regions adjacent to Yerevan

5,000֏

Delivery within 36 hours.

Regions adjacent to Yerevan

Free

Delivery within 24 hours.

Regions not adjacent to Yerevan

35,000֏

Delivery within 7 days.

Regions not adjacent to Yerevan

Free

Description Aurora Sistema 200 AC/DC PULS TIG welder, 200 A

Aurora Sistema 200 AC/DC PULS is a TIG welder: max current 200 A, duty cycle 25%.

Welding

Duty cycle 25%, input voltage 140–250 V

The welder is designed for joining steel structures, pipes and metal parts in the workshop, on site and at home.

Max current200 A

Duty cycle25%

Input voltage140–250 V

Weight13.25 kg

Product description

Aurora Sistema 200 AC/DC PULS is a TIG welder (TIG + MMA). Max current is 200 A, duty cycle 25%, input voltage 140–250 V. It weighs 13.25 kg.

Advantages

TIG AC/DC and MMA welding with pulse mode.
Welding current 5–200 A.
230 V single-phase supply.
Duty cycle 25%.
HF contactless ignition and AC/DC mode.
Pulse 0.5–500 Hz, AC frequency 15–150 Hz.
10 program memory.
Works with low mains voltage.

Technical specifications

Included in the packageMachine, TIG torch TIG-26, 4 m, gas hose with clamps 2 m, cable 2 m, earth clamp, user manual

Manufacturer countryChina

PackingBox

Weight kg13.25

Voltage (Volt)230

Power (W)5200

Welding Type(s)TIG + MMA

Maximum electrode diameter mm4.0

No-load voltage V68

Warranty period. month12

Minimum electrode diameter mm1.6

Pull Force Lbs0

Air flow (l/min)0

TypeTIG welder

Power supply typeCorded

Instrument classSemi-professional

Cable length (cm)200

Rated current A200

MMA power consumption, kVA5.2

Protection classClass I

Power factor0.7

Nominal frequency of alternating current, Hz50/60

DisplayYes

Overheat protectionYes

Maximum cutting capacity in steel 400 N/mm² (mm)0

Maximum cutting thickness in stainless steel (mm)0

Duty cycle, %25

Minimum welding current (A)5

Maximum welding current (A)200

Minimum input voltage (V)140

Maximum input voltage (V)250

Welding current typeAC/DC

Minimum wire diameter (mm)0

Maximum wire diameter (mm)0

Maximum wire spool weight (kg)0

Gasless welding (flux-cored wire)No

Hot StartYes

Arc ForceYes

Anti-StickYes

VRD (voltage reduction device)No

Ingress protection rating (IP)IP21S

Welding cable length (m)4

Cooling typeAir

Built-in compressorNo

Arc ignition typeNon-contact (HF)

Maximum weldable metal thickness (mm)6

Package contents

Machine, TIG torch TIG-26, 4 m, gas hose with clamps 2 m, cable 2 m, earth clamp, user manual.

Applications

For precise TIG welding of aluminium, stainless steel and non-ferrous metals in workshops and production.

Main attributes Aurora Sistema 200 AC/DC PULS TIG welder, 200 A

Technical

Anti-Stick Yes

Arc Force Yes

Built-in compressor No

Certificate of Conformity number

Certificate/declaration expiration date

Date of registration of the certificate/declaration

Declaration of Conformity number

Display Yes

Document number on the customs status of goods

Duty cycle, % 25

Gasless welding (flux-cored wire) No

Hot Start Yes

Ingress protection rating (IP) IP21S

Instrument class Semi-professional

Manufacturer country China

Maximum cutting capacity in steel 400 N/mm² (mm) 0

Maximum cutting thickness in stainless steel (mm) 0

Maximum weldable metal thickness (mm) 6

Maximum welding current (A) 200

Maximum wire diameter (mm) 0

Maximum wire spool weight (kg) 0

Minimum welding current (A) 5

Minimum wire diameter (mm) 0

Overheat protection Yes

Power (W) 5200

Power factor 0.7

Protection class Class I

Pull Force Lbs 0

VRD (voltage reduction device) No

Warranty period. month 12

Welding cable length (m) 4

Minimum electrode diameter mm 1.6

Maximum electrode diameter mm 4.0

Vacuum pressure

Air flow (l/min) 0

Structure

Arc ignition type Non-contact (HF)

Cooling type Air

Type TIG welder

Weight kg 13.25

Welding current type AC/DC

Welding Type(s) TIG + MMA

Nutrition

Maximum input voltage (V) 250

Minimum input voltage (V) 140

MMA power consumption, kVA 5.2

No-load voltage V 68

Nominal frequency of alternating current, Hz 50/60

Power supply type Corded

Rated current A 200

Voltage (Volt) 230

Size

Cable length (cm) 200

Packing

Packing Box

Set

Included in the package Machine, TIG torch TIG-26, 4 m, gas hose with clamps 2 m, cable 2 m, earth clamp, user manual

Reviews about Aurora Sistema 200 AC/DC PULS TIG welder, 200 A

There are no reviews for this product.

Questions and Answers (FAQ) Aurora Sistema 200 AC/DC PULS TIG welder, 200 A

There are no questions about this product.

How to use Aurora Sistema 200 AC/DC PULS TIG welder, 200 A

Soon...
