FUBAG BS 9000 A ES gasoline generator with 8.5 kW rated output

Name: FUBAG BS 9000 A ES gasoline generator with 8.5 kW rated output
Brand: FUBAG
SKU: BS-9000-A-ES
Price: 565500 AMD
Availability: InStock

Filter

Power (Watts)

Nominal power (watts)

FUBAG BS 9000 A ES gasoline generator with 9 kVA maximum output

New

In stock

Model: BS 9000 A ES

Vendor code: BS-9000-A-ES

Brand: FUBAG

565,500֏

Price in reward points: 565500

Found it cheaper?

5655 points to the account

Payment

Delivery

Delivery within 2 hours.

Yerevan

3,000֏

Delivery within 24 hours.

Yerevan

Free

Delivery within 3 hours.

Regions adjacent to Yerevan

5,000֏

Delivery within 36 hours.

Regions adjacent to Yerevan

Free

Delivery within 24 hours.

Regions not adjacent to Yerevan

35,000֏

Delivery within 7 days.

Regions not adjacent to Yerevan

Free

Description FUBAG BS 9000 A ES gasoline generator 8.5 kW, single-phase

FUBAG BS 9000 A ES is a single-phase gasoline generator with 8.5 kW rated output and up to 9 kVA maximum output.

Gasoline generator

8.5 kW rated output for dependable backup power

The FUBAG BS 9000 A ES generator is designed for mobile or backup power supply for homes, workshops, construction and service work.

Maximum output9 kVA

Rated output8.5 kW

Voltage230 V

Fuel tank36 L

Product description

FUBAG BS 9000 A ES combines 8.5 kW rated output, 230 V operating voltage and a 36 L fuel tank. The DH550 gasoline engine runs at a rated speed of 3000 rpm.

Advantages

Synchronous alternator with copper winding and AVR voltage regulation.
Overload and low-oil protection systems.
Manual and electric starting for different operating scenarios.

Technical specifications

Maximum output9 kVA

Rated output8.5 kW

Voltage230 V

Frequency50 Hz

Engine displacement550 cc

Fuel tank36 L

Weight102.8 kg

Output phases1

Package contents

Generator, matching plugs, spark-plug wrench, oil funnel, operating manual, ignition keys.

Applications

Backup power for homes, workshops, construction sites, service and mobile work.

Main attributes FUBAG BS 9000 A ES gasoline generator 8.5 kW, single-phase

Technical

Automatic Transfer Switch (ATS) No

Certificate of Conformity number

Certificate/declaration expiration date

Date of registration of the certificate/declaration

Declaration of Conformity number

Document number on the customs status of goods

Engine capacity cc 550

Engine power (Horsepower) 18

Engine type 4-stroke gasoline, 1-cylinder, air-cooled

Functions AVR voltage regulation, overload protection, low-oil engine protection

Manufacturer country Germany

Maximum sound/noise level (dB) 84

Operating temperature range, °С -15…+40

Power (W) 9000

Power factor 1

Protection class IP23

Rated output W 8500

Rated speed rpm 3000

Scope of application Backup or mobile power supply for homes, workshops, construction and service work

Special features Synchronous alternator with copper winding, AVR voltage regulation, reinforced open frame, DH550 engine

Starting system Mechanical + electrical

Warranty period. month 24

Structure

ATS connector Yes

Casing type Open

Inverter No

Number of cylinders pcs 1

Number of output phases 1

Number of sockets 12 V 0

Number of sockets 230 V 3

Number of sockets 380 V 0

USB socket 0

Weight kg 102.8

Nutrition

Fuel AI-92 gasoline

Fuel consumption g/kWh 580

Method of power supply of the instrument Gasoline engine

Nominal frequency of alternating current, Hz 50

Oil consumption g/kWh 2.5

Voltage (Volt) 230

Voltage regulation AVR

Size

Fuel tank L 36

Oil volume l 1.2

Packing

Packing Factory transport packaging

Set

Included in the package Generator, matching socket plugs, spark-plug wrench, oil funnel, operating manual, ignition keys
