Resanta SAI-180 AD TIG welder: max current 180 A

Name: Resanta SAI-180 AD TIG welder: max current 180 A
Brand: RESANTA
SKU: SV11450571
Price: 203335 AMD
Availability: InStock

Filter

Power (Watts)

MMA power consumption, kVA

New

In stock

Model: САИ-180 АД

Vendor code: SV11450571

Brand: RESANTA

203,335֏

Price in reward points: 203335

Found it cheaper?

10167 points to the account

Payment

Delivery

Delivery within 2 hours.

Yerevan

3,000֏

Delivery within 24 hours.

Yerevan

Free

Delivery within 3 hours.

Regions adjacent to Yerevan

5,000֏

Delivery within 36 hours.

Regions adjacent to Yerevan

Free

Delivery within 24 hours.

Regions not adjacent to Yerevan

35,000֏

Delivery within 7 days.

Regions not adjacent to Yerevan

Free

Description Resanta SAI-180 AD TIG welder, 180 A

Resanta SAI-180 AD is a TIG welder: max current 180 A, duty cycle 70%.

Welding

Duty cycle 70%, input voltage 207–253 V

The welder is designed for joining steel structures, pipes and metal parts in the workshop, on site and at home.

Max current180 A

Duty cycle70%

Input voltage207–253 V

Weight9 kg

Product description

Resanta SAI-180 AD is a TIG welder (TIG + MMA). Max current is 180 A, duty cycle 70%, input voltage 207–253 V. It weighs 9 kg.

Advantages

Welding current 10–180 A.
Duty cycle 70% at maximum current.
Mains supply 207–253 V.
Electrodes up to 4 mm.
TIG torch, collets and tungsten electrodes included.
HF TIG ignition, 2T/4T, digital display.

Technical specifications

Included in the packageWelding machine, TIG torch cable, earth cable, MMA electrode holder cable, collets 1.6 and 2.4 mm, tungsten electrodes 1.6 and 2.4 mm, passport

Manufacturer countryRussia

PackingBox

Weight kg9

Voltage (Volt)230

Power (W)6500

Welding Type(s)TIG + MMA

Maximum electrode diameter mm4.0

No-load voltage V85

Warranty period. month12

Minimum electrode diameter mm1.6

Pull Force Lbs0

Air flow (l/min)0

TypeTIG welder

Power supply typeCorded

Instrument classSemi-professional

Cable length (cm)200

Rated current A200

MMA power consumption, kVA6.5

Protection classClass I

Power factor0.7

Nominal frequency of alternating current, Hz50

DisplayYes

Overheat protectionYes

Maximum cutting capacity in steel 400 N/mm² (mm)0

Maximum cutting thickness in stainless steel (mm)0

Duty cycle, %70

Minimum welding current (A)10

Maximum welding current (A)180

Minimum input voltage (V)207

Maximum input voltage (V)253

Welding current typeDirect current (DC)

Minimum wire diameter (mm)0

Maximum wire diameter (mm)0

Maximum wire spool weight (kg)0

Gasless welding (flux-cored wire)No

Hot StartYes

Arc ForceYes

Anti-StickYes

VRD (voltage reduction device)No

Ingress protection rating (IP)IP21S

Welding cable length (m)2

Cooling typeAir

Built-in compressorNo

Arc ignition typeNon-contact (HF)

Maximum weldable metal thickness (mm)6

Package contents

Welding machine, TIG torch cable, earth cable, MMA electrode holder cable, collets 1.6 and 2.4 mm, tungsten electrodes 1.6 and 2.4 mm, passport.

Applications

High-quality TIG welding of stainless and mild steel, copper and titanium plus stick welding in the workshop and on site.

Main attributes Resanta SAI-180 AD TIG welder, 180 A

Technical

Anti-Stick Yes

Arc Force Yes

Built-in compressor No

Certificate of Conformity number

Certificate/declaration expiration date

Date of registration of the certificate/declaration

Declaration of Conformity number

Display Yes

Document number on the customs status of goods

Duty cycle, % 70

Gasless welding (flux-cored wire) No

Hot Start Yes

Ingress protection rating (IP) IP21S

Instrument class Semi-professional

Manufacturer country Russia

Maximum cutting capacity in steel 400 N/mm² (mm) 0

Maximum cutting thickness in stainless steel (mm) 0

Maximum weldable metal thickness (mm) 6

Maximum welding current (A) 180

Maximum wire diameter (mm) 0

Maximum wire spool weight (kg) 0

Minimum welding current (A) 10

Minimum wire diameter (mm) 0

Overheat protection Yes

Power (W) 6500

Power factor 0.7

Protection class Class I

Pull Force Lbs 0

VRD (voltage reduction device) No

Warranty period. month 12

Welding cable length (m) 2

Minimum electrode diameter mm 1.6

Maximum electrode diameter mm 4.0

Vacuum pressure

Air flow (l/min) 0

Structure

Arc ignition type Non-contact (HF)

Cooling type Air

Type TIG welder

Weight kg 9

Welding current type Direct current (DC)

Welding Type(s) TIG + MMA

Nutrition

Maximum input voltage (V) 253

Minimum input voltage (V) 207

MMA power consumption, kVA 6.5

No-load voltage V 85

Nominal frequency of alternating current, Hz 50

Power supply type Corded

Rated current A 200

Voltage (Volt) 230

Size

Cable length (cm) 200

Packing

Packing Box

Set

Included in the package Welding machine, TIG torch cable, earth cable, MMA electrode holder cable, collets 1.6 and 2.4 mm, tungsten electrodes 1.6 and 2.4 mm, passport
