Description Svarog REAL CUT 90 Air Plus plasma cutter, 80 A

Svarog REAL CUT 90 Air Plus is a plasma cutter: max current 80 A, cut up to 30 mm.
Plasma cutting

Cut up to 30 mm, input voltage 320–430 V

The plasma cutter cuts steel, stainless steel, aluminium and other conductive metals quickly and cleanly.

Max current80 A
Cut up to30 mm
Input voltage320–430 V
Weight55 kg
Product description

Svarog REAL CUT 90 Air Plus is a plasma cutter (plasma cutting). Max current is 80 A, cut up to 30 mm, input voltage 320–430 V. It weighs 55 kg.

Advantages
  • Cutting current up to 80 A.
  • Cuts steel up to 30 mm.
  • 380 V supply.
  • Overheat protection, fan cooling.
  • 60% duty cycle.
  • Built-in oil-free twin-piston compressor.
  • Digital indicator with error display.
Technical specifications
Included in the packageInverter plasma cutter with built-in compressor, P80 torch 5 m, 300 A earth clamp 3 m, spare parts kit, manual and passport
Manufacturer countryChina
PackingBox
Weight kg55
Voltage (Volt)380
Power (W)15000
Welding Type(s)Plasma cutting (CUT)
Maximum electrode diameter mm0
No-load voltage V300
Warranty period. month12
Minimum electrode diameter mm0
Pull Force Lbs0
Air flow (l/min)250
TypePlasma cutter
Power supply typeCorded
Instrument classProfessional
Cable length (cm)300
Rated current A100
MMA power consumption, kVA15
Protection classClass I
Power factor0.7
Nominal frequency of alternating current, Hz50
DisplayYes
Overheat protectionYes
Maximum cutting capacity in steel 400 N/mm² (mm)30
Maximum cutting thickness in stainless steel (mm)22
Duty cycle, %60
Minimum welding current (A)20
Maximum welding current (A)80
Minimum input voltage (V)320
Maximum input voltage (V)430
Welding current typeDirect current (DC)
Minimum wire diameter (mm)0
Maximum wire diameter (mm)0
Maximum wire spool weight (kg)0
Gasless welding (flux-cored wire)No
Hot StartNo
Arc ForceNo
Anti-StickNo
VRD (voltage reduction device)No
Ingress protection rating (IP)IP23S
Welding cable length (m)5
Cooling typeAir
Built-in compressorYes
Arc ignition typeNon-contact (HF)
Maximum weldable metal thickness (mm)0
Package contents
Inverter plasma cutter with built-in compressor, P80 torch 5 m, 300 A earth clamp 3 m, spare parts kit, manual and passport.
Applications
Heavy-duty cutting of thick metal in steel fabrication, ship repair and industrial workshops.

Main attributes Svarog REAL CUT 90 Air Plus plasma cutter, 80 A

Technical
Anti-Stick No
Arc Force No
Built-in compressor Yes
Certificate of Conformity number
Certificate/declaration expiration date
Date of registration of the certificate/declaration
Declaration of Conformity number
Display Yes
Document number on the customs status of goods
Duty cycle, % 60
Gasless welding (flux-cored wire) No
Hot Start No
Ingress protection rating (IP) IP23S
Instrument class Professional
Manufacturer country China
Maximum cutting capacity in steel 400 N/mm² (mm) 30
Maximum cutting thickness in stainless steel (mm) 22
Maximum weldable metal thickness (mm) 0
Maximum welding current (A) 80
Maximum wire diameter (mm) 0
Maximum wire spool weight (kg) 0
Minimum welding current (A) 20
Minimum wire diameter (mm) 0
Overheat protection Yes
Power (W) 15000
Power factor 0.7
Protection class Class I
Pull Force Lbs 0
VRD (voltage reduction device) No
Warranty period. month 12
Welding cable length (m) 5
Minimum electrode diameter mm 0
Maximum electrode diameter mm 0
Vacuum pressure
Air flow (l/min) 250
Structure
Arc ignition type Non-contact (HF)
Cooling type Air
Type Plasma cutter
Weight kg 55
Welding current type Direct current (DC)
Welding Type(s) Plasma cutting (CUT)
Nutrition
Maximum input voltage (V) 430
Minimum input voltage (V) 320
MMA power consumption, kVA 15
No-load voltage V 300
Nominal frequency of alternating current, Hz 50
Power supply type Corded
Rated current A 100
Voltage (Volt) 380
Size
Cable length (cm) 300
Packing
Packing Box
Set
Included in the package Inverter plasma cutter with built-in compressor, P80 torch 5 m, 300 A earth clamp 3 m, spare parts kit, manual and passport
