Svarog TIG 315 P AC/DC MULTIWAVE TIG welder: max current 315 A

Filter
27222 - 4279034 ֏ Price
- ֏
Stock status
Display
Duty cycle, %
Type
Power (Watts)
4.25 - 140 Weight
-
New
Instrument class
Maximum electrode diameter (mm)
Brand
Maximum welding current (A)
Supply voltage (V)
Welding Type(s)
Maximum cutting capacity in steel 400 N/mm² (mm)
Welding current type
Maximum wire diameter (mm)
Gasless welding (flux-cored wire)
MMA power consumption, kVA
Rated current A
New
In stock
Model: TIG 315 P AC/DC MULTIWAVE
Vendor code: SV61958879
Brand: Svarog
1,088,898֏
Price in reward points: 1088898
Found it cheaper?
10889 points to the account
Payment
Delivery
Delivery within 2 hours.
Delivery within 2 hours.
Yerevan
3,000֏
Delivery within 24 hours.
Delivery within 24 hours.
Yerevan
Free
Delivery within 3 hours.
Delivery within 3 hours.
Regions adjacent to Yerevan
5,000֏
Delivery within 36 hours.
Delivery within 36 hours.
Regions adjacent to Yerevan
Free
Delivery within 24 hours.
Delivery within 24 hours.
Regions not adjacent to Yerevan
35,000֏
Delivery within 7 days.
Delivery within 7 days.
Regions not adjacent to Yerevan
Free

Description Svarog TIG 315 P AC/DC MULTIWAVE TIG welder, 315 A

Svarog TIG 315 P AC/DC MULTIWAVE is a TIG welder: max current 315 A, duty cycle 60%.
Welding

Duty cycle 60%, input voltage 320–430 V

The welder is designed for joining steel structures, pipes and metal parts in the workshop, on site and at home.

Max current315 A
Duty cycle60%
Input voltage320–430 V
Weight26 kg
Product description

Svarog TIG 315 P AC/DC MULTIWAVE is a TIG welder (TIG + MMA). Max current is 315 A, duty cycle 60%, input voltage 320–430 V. It weighs 26 kg.

Advantages
  • TIG AC/DC, AC/DC pulse, MIX mode, selectable waveforms.
  • Current TIG 5–315 A, MMA 10–270 A.
  • Three-phase 380 V (320–430 V), 60% duty cycle.
  • 50 program memory, 2T/4T, SPOT.
  • Hot Start, Arc Force, Antistick, switchable VRD.
  • Water-cooler and foot pedal connection.
Technical specifications
Included in the packageWelding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual
Manufacturer countryChina
PackingBox
Weight kg26
Voltage (Volt)380
Power (W)14900
Welding Type(s)TIG + MMA
Maximum electrode diameter mm5.0
No-load voltage V68
Warranty period. month12
Minimum electrode diameter mm1.6
Pull Force Lbs0
Air flow (l/min)0
TypeTIG welder
Power supply typeCorded
Instrument classProfessional
Cable length (cm)300
Rated current A300
MMA power consumption, kVA14.9
Protection classClass I
Power factor0.7
Nominal frequency of alternating current, Hz50
DisplayYes
Overheat protectionYes
Maximum cutting capacity in steel 400 N/mm² (mm)0
Maximum cutting thickness in stainless steel (mm)0
Duty cycle, %60
Minimum welding current (A)5
Maximum welding current (A)315
Minimum input voltage (V)320
Maximum input voltage (V)430
Welding current typeAC/DC
Minimum wire diameter (mm)0
Maximum wire diameter (mm)0
Maximum wire spool weight (kg)0
Gasless welding (flux-cored wire)No
Hot StartYes
Arc ForceYes
Anti-StickYes
VRD (voltage reduction device)Yes
Ingress protection rating (IP)IP23S
Welding cable length (m)4
Cooling typeAir
Built-in compressorNo
Arc ignition typeNon-contact (HF)
Maximum weldable metal thickness (mm)10
Package contents
Welding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual.
Applications
TIG welding of aluminium, stainless and mild steel and copper in production, car service and professional workshops.

Main attributes Svarog TIG 315 P AC/DC MULTIWAVE TIG welder, 315 A

Technical
Anti-Stick Yes
Arc Force Yes
Built-in compressor No
Certificate of Conformity number
Certificate/declaration expiration date
Date of registration of the certificate/declaration
Declaration of Conformity number
Display Yes
Document number on the customs status of goods
Duty cycle, % 60
Gasless welding (flux-cored wire) No
Hot Start Yes
Ingress protection rating (IP) IP23S
Instrument class Professional
Manufacturer country China
Maximum cutting capacity in steel 400 N/mm² (mm) 0
Maximum cutting thickness in stainless steel (mm) 0
Maximum weldable metal thickness (mm) 10
Maximum welding current (A) 315
Maximum wire diameter (mm) 0
Maximum wire spool weight (kg) 0
Minimum welding current (A) 5
Minimum wire diameter (mm) 0
Overheat protection Yes
Power (W) 14900
Power factor 0.7
Protection class Class I
Pull Force Lbs 0
VRD (voltage reduction device) Yes
Warranty period. month 12
Welding cable length (m) 4
Minimum electrode diameter mm 1.6
Maximum electrode diameter mm 5.0
Vacuum pressure
Air flow (l/min) 0
Structure
Arc ignition type Non-contact (HF)
Cooling type Air
Type TIG welder
Weight kg 26
Welding current type AC/DC
Welding Type(s) TIG + MMA
Nutrition
Maximum input voltage (V) 430
Minimum input voltage (V) 320
MMA power consumption, kVA 14.9
No-load voltage V 68
Nominal frequency of alternating current, Hz 50
Power supply type Corded
Rated current A 300
Voltage (Volt) 380
Size
Cable length (cm) 300
Packing
Packing Box
Set
Included in the package Welding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual
