Description Svarog TIG 315P AC/DC MULTIWAVE PRO E202 TIG welder, 315 A

Svarog TIG 315P AC/DC MULTIWAVE PRO E202 is a TIG welder: max current 315 A, duty cycle 60%.
Welding

Duty cycle 60%, input voltage 320–430 V

The welder is designed for joining steel structures, pipes and metal parts in the workshop, on site and at home.

Max current315 A
Duty cycle60%
Input voltage320–430 V
Weight25.5 kg
Product description

Svarog TIG 315P AC/DC MULTIWAVE PRO E202 is a TIG welder (TIG + MMA). Max current is 315 A, duty cycle 60%, input voltage 320–430 V. It weighs 25.5 kg.

Advantages
  • TIG AC/DC, AC/DC pulse, MIX, selectable waveforms.
  • Current TIG 5–315 A, MMA 10–270 A.
  • Three-phase 380 V, 60% duty cycle, IP23S.
  • 50 program memory, digital torch connection.
  • HF or Lift ignition, switchable VRD.
  • Hot Start, Arc Force, Antistick, air-arc gouging.
Technical specifications
Included in the packageWelding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual
Manufacturer countryChina
PackingBox
Weight kg25.5
Voltage (Volt)380
Power (W)14900
Welding Type(s)TIG + MMA
Maximum electrode diameter mm5.0
No-load voltage V76
Warranty period. month12
Minimum electrode diameter mm1.6
Pull Force Lbs0
Air flow (l/min)0
TypeTIG welder
Power supply typeCorded
Instrument classProfessional
Cable length (cm)300
Rated current A300
MMA power consumption, kVA14.9
Protection classClass I
Power factor0.7
Nominal frequency of alternating current, Hz50
DisplayYes
Overheat protectionYes
Maximum cutting capacity in steel 400 N/mm² (mm)0
Maximum cutting thickness in stainless steel (mm)0
Duty cycle, %60
Minimum welding current (A)5
Maximum welding current (A)315
Minimum input voltage (V)320
Maximum input voltage (V)430
Welding current typeAC/DC
Minimum wire diameter (mm)0
Maximum wire diameter (mm)0
Maximum wire spool weight (kg)0
Gasless welding (flux-cored wire)No
Hot StartYes
Arc ForceYes
Anti-StickYes
VRD (voltage reduction device)Yes
Ingress protection rating (IP)IP23S
Welding cable length (m)4
Cooling typeAir
Built-in compressorNo
Arc ignition typeNon-contact (HF)
Maximum weldable metal thickness (mm)10
Package contents
Welding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual.
Applications
TIG welding of aluminium, stainless and mild steel and copper in production, car service and professional workshops.

Main attributes Svarog TIG 315P AC/DC MULTIWAVE PRO E202 TIG welder, 315 A

Technical
Anti-Stick Yes
Arc Force Yes
Built-in compressor No
Certificate of Conformity number
Certificate/declaration expiration date
Date of registration of the certificate/declaration
Declaration of Conformity number
Display Yes
Document number on the customs status of goods
Duty cycle, % 60
Gasless welding (flux-cored wire) No
Hot Start Yes
Ingress protection rating (IP) IP23S
Instrument class Professional
Manufacturer country China
Maximum cutting capacity in steel 400 N/mm² (mm) 0
Maximum cutting thickness in stainless steel (mm) 0
Maximum weldable metal thickness (mm) 10
Maximum welding current (A) 315
Maximum wire diameter (mm) 0
Maximum wire spool weight (kg) 0
Minimum welding current (A) 5
Minimum wire diameter (mm) 0
Overheat protection Yes
Power (W) 14900
Power factor 0.7
Protection class Class I
Pull Force Lbs 0
VRD (voltage reduction device) Yes
Warranty period. month 12
Welding cable length (m) 4
Minimum electrode diameter mm 1.6
Maximum electrode diameter mm 5.0
Vacuum pressure
Air flow (l/min) 0
Structure
Arc ignition type Non-contact (HF)
Cooling type Air
Type TIG welder
Weight kg 25.5
Welding current type AC/DC
Welding Type(s) TIG + MMA
Nutrition
Maximum input voltage (V) 430
Minimum input voltage (V) 320
MMA power consumption, kVA 14.9
No-load voltage V 76
Nominal frequency of alternating current, Hz 50
Power supply type Corded
Rated current A 300
Voltage (Volt) 380
Size
Cable length (cm) 300
Packing
Packing Box
Set
Included in the package Welding inverter, TIG torch TECH TS 18, 4 m, earth clamp assembly 300 A, 3 m, spare parts kit, passport and operating manual
