Description Fubag Plasma 50 AIR plasma cutter, 50 A

Fubag Plasma 50 AIR is a plasma cutter: max current 50 A, cut up to 15 mm.

Plasma cutting

Cut up to 15 mm, input voltage 198–242 V

The plasma cutter cuts steel, stainless steel, aluminium and other conductive metals quickly and cleanly.

Max current50 A

Cut up to15 mm

Input voltage198–242 V

Weight21.7 kg

Product description

Fubag Plasma 50 AIR is a plasma cutter (plasma cutting). Max current is 50 A, cut up to 15 mm, input voltage 198–242 V. It weighs 21.7 kg.

Advantages

Cutting current up to 50 A.
Cuts steel up to 15 mm thick.
Cuts mild and stainless steel, aluminium, copper.
Overheat protection and fan cooling.
Built-in oil-free compressor, no external air needed.
Digital display.

Technical specifications

Included in the packagePlasma 50 AIR unit with built-in compressor, FB P40 6 m torch, protective cap (2 pcs), 10 mm² 4 m earth cable, 3 m gas hose, manual

Manufacturer countryGermany

PackingBox

Weight kg21.7

Voltage (Volt)230

Power (W)8600

Welding Type(s)Plasma cutting (CUT)

Maximum electrode diameter mm0

No-load voltage V325

Warranty period. month12

Minimum electrode diameter mm0

Pull Force Lbs0

Air flow (l/min)250

TypePlasma cutter

Power supply typeCorded

Instrument classSemi-professional

Cable length (cm)200

Rated current A100

MMA power consumption, kVA8.6

Protection classClass I

Power factor0.75

Nominal frequency of alternating current, Hz50

DisplayYes

Overheat protectionYes

Maximum cutting capacity in steel 400 N/mm² (mm)15

Maximum cutting thickness in stainless steel (mm)12

Duty cycle, %50

Minimum welding current (A)20

Maximum welding current (A)50

Minimum input voltage (V)198

Maximum input voltage (V)242

Welding current typeDirect current (DC)

Minimum wire diameter (mm)0

Maximum wire diameter (mm)0

Maximum wire spool weight (kg)0

Gasless welding (flux-cored wire)No

Hot StartNo

Arc ForceNo

Anti-StickNo

VRD (voltage reduction device)No

Ingress protection rating (IP)IP21S

Welding cable length (m)6

Cooling typeAir

Built-in compressorYes

Arc ignition typePilot arc

Maximum weldable metal thickness (mm)0

Package contents

Plasma 50 AIR unit with built-in compressor, FB P40 6 m torch, protective cap (2 pcs), 10 mm² 4 m earth cable, 3 m gas hose, manual.

Applications

Fast cutting of sheet metal, pipes and profiles in workshops, on construction sites and in steel fabrication.

Main attributes Fubag Plasma 50 AIR plasma cutter, 50 A

Technical

Anti-Stick No

Arc Force No

Built-in compressor Yes

Certificate of Conformity number

Certificate/declaration expiration date

Date of registration of the certificate/declaration

Declaration of Conformity number

Display Yes

Document number on the customs status of goods

Duty cycle, % 50

Gasless welding (flux-cored wire) No

Hot Start No

Ingress protection rating (IP) IP21S

Instrument class Semi-professional

Manufacturer country Germany

Maximum cutting capacity in steel 400 N/mm² (mm) 15

Maximum cutting thickness in stainless steel (mm) 12

Maximum weldable metal thickness (mm) 0

Maximum welding current (A) 50

Maximum wire diameter (mm) 0

Maximum wire spool weight (kg) 0

Minimum welding current (A) 20

Minimum wire diameter (mm) 0

Overheat protection Yes

Power (W) 8600

Power factor 0.75

Protection class Class I

Pull Force Lbs 0

VRD (voltage reduction device) No

Warranty period. month 12

Welding cable length (m) 6

Minimum electrode diameter mm 0

Maximum electrode diameter mm 0

Vacuum pressure

Air flow (l/min) 250

Structure

Arc ignition type Pilot arc

Cooling type Air

Type Plasma cutter

Weight kg 21.7

Welding current type Direct current (DC)

Welding Type(s) Plasma cutting (CUT)

Nutrition

Maximum input voltage (V) 242

Minimum input voltage (V) 198

MMA power consumption, kVA 8.6

No-load voltage V 325

Nominal frequency of alternating current, Hz 50

Power supply type Corded

Rated current A 100

Voltage (Volt) 230

Size

Cable length (cm) 200

Packing

Packing Box

Set

Included in the package Plasma 50 AIR unit with built-in compressor, FB P40 6 m torch, protective cap (2 pcs), 10 mm² 4 m earth cable, 3 m gas hose, manual
