Description Aurora AIRFORCE 60M plasma cutter, 60 A

Aurora AIRFORCE 60M is a plasma cutter: max current 60 A, cut up to 20 mm.

Plasma cutting

Cut up to 20 mm, input voltage 340–440 V

The plasma cutter cuts steel, stainless steel, aluminium and other conductive metals quickly and cleanly.

Max current60 A

Cut up to20 mm

Input voltage340–440 V

Weight14 kg

Product description

Aurora AIRFORCE 60M is a plasma cutter (plasma cutting). Max current is 60 A, cut up to 20 mm, input voltage 340–440 V. It weighs 14 kg.

Advantages

Cutting current 20–60 A.
Max cut thickness in carbon steel 20 mm.
Power supply 400 V (three-phase), input power 10 kVA.
Compressed air consumption up to 150 l/min (external compressor).
High-frequency (HF) ignition without pilot arc.
MOSFET inverter, adjustable purge 5–20 s.

Technical specifications

Included in the packageMachine, AG60 (SG-55) plasma torch, 5 m, 300 A earth clamp, 6 mm² cable, 3 m, air filter-regulator, 8×12 gas hose, 3 m, user manual

Manufacturer countryChina

PackingBox

Weight kg14

Voltage (Volt)400

Power (W)10000

Welding Type(s)Plasma cutting (CUT)

Maximum electrode diameter mm0

No-load voltage V280

Warranty period. month12

Minimum electrode diameter mm0

Pull Force Lbs0

Air flow (l/min)150

TypePlasma cutter

Power supply typeCorded

Instrument classProfessional

Cable length (cm)300

Rated current A100

MMA power consumption, kVA10

Protection classClass I

Power factor0.93

Nominal frequency of alternating current, Hz50/60

DisplayYes

Overheat protectionYes

Maximum cutting capacity in steel 400 N/mm² (mm)20

Maximum cutting thickness in stainless steel (mm)12

Duty cycle, %60

Minimum welding current (A)20

Maximum welding current (A)60

Minimum input voltage (V)340

Maximum input voltage (V)440

Welding current typeDirect current (DC)

Minimum wire diameter (mm)0

Maximum wire diameter (mm)0

Maximum wire spool weight (kg)0

Gasless welding (flux-cored wire)No

Hot StartNo

Arc ForceNo

Anti-StickNo

VRD (voltage reduction device)No

Ingress protection rating (IP)IP21S

Welding cable length (m)5

Cooling typeAir

Built-in compressorNo

Arc ignition typeNon-contact (HF)

Maximum weldable metal thickness (mm)0

Package contents

Machine, AG60 (SG-55) plasma torch, 5 m, 300 A earth clamp, 6 mm² cable, 3 m, air filter-regulator, 8×12 gas hose, 3 m, user manual.

Applications

Cutting sheets and pipes of carbon and stainless steel, aluminium, copper and other conductive metals in workshops, metal fabrication and dismantling.

Main attributes Aurora AIRFORCE 60M plasma cutter, 60 A

Technical

Anti-Stick No

Arc Force No

Built-in compressor No

Certificate of Conformity number

Certificate/declaration expiration date

Date of registration of the certificate/declaration

Declaration of Conformity number

Display Yes

Document number on the customs status of goods

Duty cycle, % 60

Gasless welding (flux-cored wire) No

Hot Start No

Ingress protection rating (IP) IP21S

Instrument class Professional

Manufacturer country China

Maximum cutting capacity in steel 400 N/mm² (mm) 20

Maximum cutting thickness in stainless steel (mm) 12

Maximum weldable metal thickness (mm) 0

Maximum welding current (A) 60

Maximum wire diameter (mm) 0

Maximum wire spool weight (kg) 0

Minimum welding current (A) 20

Minimum wire diameter (mm) 0

Overheat protection Yes

Power (W) 10000

Power factor 0.93

Protection class Class I

Pull Force Lbs 0

VRD (voltage reduction device) No

Warranty period. month 12

Welding cable length (m) 5

Minimum electrode diameter mm 0

Maximum electrode diameter mm 0

Vacuum pressure

Air flow (l/min) 150

Structure

Arc ignition type Non-contact (HF)

Cooling type Air

Type Plasma cutter

Weight kg 14

Welding current type Direct current (DC)

Welding Type(s) Plasma cutting (CUT)

Nutrition

Maximum input voltage (V) 440

Minimum input voltage (V) 340

MMA power consumption, kVA 10

No-load voltage V 280

Nominal frequency of alternating current, Hz 50/60

Power supply type Corded

Rated current A 100

Voltage (Volt) 400

Size

Cable length (cm) 300

Packing

Packing Box

Set

Included in the package Machine, AG60 (SG-55) plasma torch, 5 m, 300 A earth clamp, 6 mm² cable, 3 m, air filter-regulator, 8×12 gas hose, 3 m, user manual
